| 1. Features |
- 20A switching capabilities
- High resistance to vibraiton and shock
- Low power consumption 0.6W only |
| 2. Sealed Types Availability |
 |
| 3. Latching Types Availability |
|
| 4. Mounting Method |
Plug-in |
|
| PC Board |
|
| Top-mount |
|
| 5. Contact Arrangement |
1c |
| 6. Contact Raiting(resistive) |
N.O.: 20A 14VDC
N.O.: 10A 14VDC |
| 7. Contact Material |
Silver alloy |
8. Expected Life
8. (min. operations) |
Electrical (at rated load) |
1 x 105 |
| Mechanical |
1 x 107 |
| 9. Breakdown Voltage |
BetweenOpen Contacts |
500VAC |
| Between Contact Sets |
- |
| Between Contacts&Coil |
500VAC |
| 10. Surge Withstand Voltage |
- |
| 11. Coil Voltage |
(DC) 6, 9, 10, 12 |
| 12. Norminal Operating Power |
0.60W |
| 13. Approved Operating Standards |
 |
