| Features |
ㆍSmall size, light weight, Low coil power consumption,
heavy contact load.
ㆍStrong anti-shock and anti-vibration, high reliability, long life.
ㆍSuitable for automobile, machine, electronic equipment, air conditioner and household appliance applications
PC board mounting.
|
| Ordering
Information |
 |
1 Part number :NT90(T90)
2 Terminal : R : without Pin6 ; NIL: With Pin 6
3 Load : H:30A: N:40A
4 Contact arrangement : 1A:1A; 1B:1B; 1C:1C
5 Enclosure:
S:Sealed type; D:Dust cover;
E:Covered; O:Open type |
6 Coil rated Voltage(V) :
AC: 12, 24, 110, 120, 220
DC: 3, 5, 6, 9, 12, 15, 18, 24, 48, 110
7 Contact material:
C:AgCdO; S:AgSnO2
8 Resist heat class: B:130℃ F:155℃
9 Coil power consumption:
0.6:0.6W; 0.9:0.9W, NIL:2VA
|
Contact Data
| Contact Arrangement |
1A(SPSTNO), 1B(SPSTNC), 1C(SPDT(B-M)) |
| Contact Material |
AgCdO AgSnO2 AgSnO2In2O3 |
Contact Rating
(resistive) |
NO:30A/240VAC,14VDC; NO:20A/240VAC;30A/14VDC
NO:40A/250VAC,30VDC;NC:30A/250VAC,30VDC(0.9W)
NO:30A/277VAC;NC:20A/277VAC
Motor load: 2HP 250VAC; 1.5HP 250V
Lamp load: TV-5 |
| Max. Switching Power |
1100W 7200VA |
| Max. Switching Voltage |
110DC 250VAC Max.Switching
Current:40A |
| Max.Switching
Current |
40A |
Contact Resistance or
Voltage drop |
≤30mΩ Item 3.12of IEC255-7 |
| Operational life |
Electrical |
105 Item 3.30 of IEC255-7 |
| Mechanical |
107 Item 3.31 of IEC255-7 |
Coil Parameter
Dash
numbers |
Ratedl voltage
V |
Coil
resistance
Ω±10% |
Pick up
voltage
VAC(max)
(75% of rated
voltage) |
Pick up
voltage
VAC(min)
(30% of rated
voltage) |
Coil
power |
Operate
Time
ms |
Release
Time
ms |
| Rated |
Max |
| 012AC |
12 |
15.6 |
27 |
9.0 |
3.6 |
2VA |
- |
- |
| 024AC |
24 |
31.2 |
120 |
18.0 |
7.2 |
| 110AC |
110 |
143 |
2360 |
82.5 |
33.0 |
| 120AC |
120 |
156 |
3040 |
90.0 |
36.0 |
| 220AC |
220 |
286 |
13490 |
165.0 |
66.0 |
Coil Parameter
DC Coil Parameter
Dash
numbers |
Rated voltage
V |
Coil
resistance
Ω±10% |
Pick up
voltage
V(max)
(75% of rated
voltage) |
Pick up
voltage
V(min)
(10 %of rated
voltage) |
Coil
power
W |
Operate
Time
ms |
Release
Time
ms |
| Rated |
Max |
| 003-900 |
3 |
3.9 |
10 |
2.25 |
0.3 |
0.9 |
＜15 |
＜10 |
| 005-900 |
5 |
6.5 |
28 |
3.75 |
0.5 |
| 006-900 |
6 |
7.8 |
40 |
4.50 |
0.6 |
| 009-900 |
9 |
11.7 |
90 |
6.75 |
0.9 |
| 012-900 |
12 |
15.6 |
160 |
9.00 |
1.2 |
| 015-900 |
15 |
19.5 |
250 |
10.25 |
1.5 |
| 018-900 |
18 |
23.4 |
360 |
13.50 |
1.8 |
| 024-900 |
24 |
31.2 |
640 |
18.00 |
2.4 |
| 048-900 |
48 |
62.4 |
2560 |
36.00 |
4.8 |
| 110-900 |
110 |
143 |
13445 |
82.50 |
11.0 |
CAUTION :
1. The use of
any coil voltage less than the rated coil voltage will compromise
the operation of the relay.
2. Pickup and release voltage are for test purposes only and are
not to be used as design criteria.
Operation condition
| Insulation Resistance |
1000MΩmin(at 500VDC) |
Item 7 of IEC255-5 |
Dielectric Strength
Between contacts
Between contact and coil |
50㎐ 1500V
50㎐ 2500V 4000V (without Pin 6) |
Item 6 of IEC255-5
Item 6 of IEC255-5 |
| Shock resistance |
200㎳2 11㎳ |
IEC68-2-27 Test Ea |
| Vibration resistance |
10~55㎐ double amplitude 1.5mm |
IEC68-2-6 Test Fc |
| Terminals strength |
10N |
IEC68-2-21 Test Ua1 |
| Solderability |
235℃± 2℃ 3±0.5s |
IEC68-2-20 Test method 1 |
| Ambient Temperature |
-55~100℃ -55~125℃ |
|
| Relative Humidity |
85%(at 40℃) |
IEC68-2-3 Test Ca |
| Mass |
27g (Open type) 30g |
|
|
