ARA 100
  Features
  ㆍWide AC Input Voltage Range
ㆍDC Input available
ㆍLow Ripple & Noise
ㆍMeets Recognized International Standards
ARA100 Series
  ARA100-5 ARA100-12 ARA100-24
INPUT VOLTAGE 100~120VAC/200~240VAC AC85 ~ 264V AC85 ~ 264V
FREQUENCY 50/ 60Hz 50/ 60Hz 50/ 60Hz
INPUT CURRENT 100V ~ 1.4A 100V ~1.4A 100V ~ 1.4A
200V ~ 0.7A 200V ~ 0.7A 200V ~ 0.7A
EFFICIENCY 81% 85% 85%
OUTPUT VOLTAGE 5V 12V 24V
OUTPUT CURRUNT 20.0A 8.3A 4.2A
RIPPLE (mV) 60 MAX 130 MAX 260 MAX
NOISE (mV) 120 MAX 200 MAX 330 MAX
OPERATING TEMP&HUMD '-10 ~ +50℃,
20 ~ 90% RH		 '-10 ~ +50℃,
20 ~ 90% RH		 '-10 ~ +50℃,
20 ~ 90% RH
