제품소개 > SMPS > ARA 200
ARA 200
  Features
  ㆍWide AC Input Voltage Range
ㆍDC Input available
ㆍLow Ripple & Noise
ㆍMeets Recognized International Standards
ARA200 Series
  ARA200-5 ARA200-12 ARA200-24
INPUT VOLTAGE 100~120VAC/200~240VAC 100~120VAC/200~240VAC 100~120VAC/200~240VAC
FREQUENCY 50/ 60Hz 50/ 60Hz 50/ 60Hz
INPUT CURRENT 100V ~ 3.9A 100V ~3.9A 100V ~3.9A
200V ~ 1.5A 200V ~ 1.5A 200V ~ 1.5A
EFFICIENCY 80% 85% 85%
OUTPUT VOLTAGE 5V 12V 24V
OUTPUT CURRUNT 40.0A 17.0A 8.3A
RIPPLE (mV) 110 MAX 140 MAX 270 MAX
NOISE (mV) 160 MAX 220 MAX 340 MAX
OPERATING TEMP&HUMD '-10 ~ +50℃,
20 ~ 90% RH		 '-10 ~ +50℃,
20 ~ 90% RH		 '-10 ~ +50℃,
20 ~ 90% RH
