ARA 30
  Features
  ㆍWide AC Input Voltage Range
ㆍDC Input available
ㆍLow Ripple & Noise
ㆍMeets Recognized International Standards
ARA30 Series
  ARA30-5 ARA30-12 ARA30-24
INPUT VOLTAGE AC85 ~ 264V AC85 ~ 264V AC85 ~ 264V
FREQUENCY 50/ 60Hz 50/ 60Hz 50/ 60Hz
INPUT CURRENT 100V ~ 0.6A 100V ~ 0.6A 100V ~ 0.6A
200V ~ 0.35A 200V ~ 0.35A 200V ~ 0.35A
EFFICIENCY 79% 80% 82%
OUTPUT VOLTAGE 5V 12V 24V
OUTPUT CURRUNT 6.0A 2.5A 1.25A
RIPPLE (mV) 60 MAX 130 MAX 250 MAX
NOISE (mV) 120 MAX 190 MAX 320 MAX
OPERATING TEMP&HUMD '-10 ~ + 50℃,
20 ~ 90% RH		 '-10 ~ + 50℃,
20 ~ 90% RH		 '-10 ~ + 50℃,
20 ~ 90% RH
